Edilians HP10 Clay Tile

Edilians HP10 Clay Tile

A large, flat, elegant clay tile, the HP10 has a thin, tapered leading edge. It is laid broken bonded and is supported by a comprehensive range of matching fittings and accessories.
This modern tile has proved to be a natural winner on countless new build projects. It is suitable for traditional or modern dry-fix installation and is available in five distinctive colours.

Technical Data

Quantity per pallet:
240 tiles
Coverage
10 per m2 @ max 376mm gauge

Nominal gauge (variable):

310mm minimum / 376mm maximum
Linear Cover:
268mm
Minimum Headlap:
84mm
Unit Weight:
4.3kg
Weight per m2:
43kg @ 10m2 / 56kg @ 13m2
Minimum Roof Pitch:
17.5° sheltered areas only

Batten coverage:

2.68 per m2 @ max gauge
Nail Size:
50 x 3.35mm Alloy
Batten Sizes:
25 x 38mm rafter centres 450mm / 25 x 50mm rafter centres 600mm

Colour Options

Argentique

Argentique

Special Order Only

Brown

Special Order Only

Burnt Red

Special Order Only

Natural Red

Special Order Only

Quartz Grey

Special Order Only

Slate

Special Order Only

Icon

Need to help or advice?

Whatever your question speak to a member of our team on 02380 862 309 or
Contact Us
The large modular size of the HP10 combines with a variable gauge to ensure economy and ease of fixing plus compatibility with Edilians solar PV systems. The HP10 is a natural and cost effective alternative to many larger format concrete tiles and slates.
